產品名稱：GWDL-FT高溫陶瓷纖維貼面塊
型號：GWDL-FT高溫陶瓷纖維貼面塊
規格：GWDL-FT高溫陶瓷纖維貼面塊
備注：GWDL-FT高溫陶瓷纖維貼面塊
由多晶氧化鋁纖維經特殊工藝整理切割、壓縮而成。不含任何結合劑或其它成分，具有極好的彈性和柔韌性,最高使用溫度可達1600℃。在氧化氣氛、中性氣氛長期使用時，仍能保持其原有的韌性、強度、柔軟度和纖維結構，不含渣球，可用由各種高溫工業窯爐的熱面內襯粘貼,隔熱性能良好。
Polycrystalline Alumina Fiber Module-cuted is from polycrystalline alumina fiber by special process finishing cutting, compression formed. Does not contain any binders or other ingredients, with excellent elasticity and flexibility, the maximum temperature up to 1600 ℃. They oxidizing atmosphere, the neutral atmosphere, the long-term bear this temperature, still maintain their original toughness, strength, flexibility and fiber structure, and non-residue ball, can be used by a variety of high-temperature industrial furnaces hot face lining paste, has a special significant insulation performance .
應 用Application
加熱爐，均熱爐，熱處理窯，陶瓷快速燒成窯等的工作襯貼面及爐門爐蓋封閉材料。
Used as module-cuted of working lining for various furnace such as heating furnace, soaking furnace, heat treatment furnace, and ceramic fast firing kiln, and sealing materials for furnace door or cover.
產品性能：Product specification：
產品牌號 Product brand | GWDL-FT-1300 | GWDL-FT-1450 | GWDL-FT-1600 | GWDL-FT-1700 |
最高使用溫度，℃ Max. service temperature | 1300 | 1450 | 1600 | 1700 |
類別 | 高鋁 | 含鋯 | 多晶 | 多晶 |
加熱線變化，% Linear shrinkage on heating | 1200×24h≤-3 | 1300×24h≤-3 | 1500×24h≤-3 | 1600×24h≤-3 |
化學成分，% Chemical compositions | Al?O? | ≥54 | ≥36 | ≥72 | ≥80 |
SiO2 | ≥46 | ≥48 | ≥28 | ≥20 |
Al?O?+ SiO2 | ≥99 | —— | ≥99.5 | ≥99.5 |
Fe?O? | ≤0.2 | ≤0.1 | —— | —— |
ZrO2 | —— | ≥15 | —— | —— |
產品規格,mm Product specification | 標準規格： 200×100×30-80（長* 寬 *高 ） Standard: 200×100×30-80 (Length * width * thickness) 也可根據用戶要求定做 In accordance with design drawing of use |
|
|
注：產品的技術數據是由所采用的測試標準得的平均值，會在一定的范圍內波動，該數據不代表產品的質量保證數據。
由多晶氧化鋁纖維經特殊工藝整理切割、壓縮而成。不含任何結合劑或其它成分，具有極好的彈性和柔韌性,最高使用溫度可達1600℃。在氧化氣氛、中性氣氛長期使用時，仍能保持其原有的韌性、強度、柔軟度和纖維結構，不含渣球，可用由各種高溫工業窯爐的熱面內襯粘貼,隔熱性能良好。
Polycrystalline Alumina Fiber Module-cuted is from polycrystalline alumina fiber by special process finishing cutting, compression formed. Does not contain any binders or other ingredients, with excellent elasticity and flexibility, the maximum temperature up to 1600 ℃. They oxidizing atmosphere, the neutral atmosphere, the long-term bear this temperature, still maintain their original toughness, strength, flexibility and fiber structure, and non-residue ball, can be used by a variety of high-temperature industrial furnaces hot face lining paste, has a special significant insulation performance .
應 用Application
加熱爐，均熱爐，熱處理窯，陶瓷快速燒成窯等的工作襯貼面及爐門爐蓋封閉材料。
Used as module-cuted of working lining for various furnace such as heating furnace, soaking furnace, heat treatment furnace, and ceramic fast firing kiln, and sealing materials for furnace door or cover.
產品性能：Product specification：
產品牌號 Product brand | GWDL-FT-1300 | GWDL-FT-1450 | GWDL-FT-1600 | GWDL-FT-1700 |
最高使用溫度，℃ Max. service temperature | 1300 | 1450 | 1600 | 1700 |
類別 | 高鋁 | 含鋯 | 多晶 | 多晶 |
加熱線變化，% Linear shrinkage on heating | 1200×24h≤-3 | 1300×24h≤-3 | 1500×24h≤-3 | 1600×24h≤-3 |
化學成分，% Chemical compositions | Al?O? | ≥54 | ≥36 | ≥72 | ≥80 |
SiO2 | ≥46 | ≥48 | ≥28 | ≥20 |
Al?O?+ SiO2 | ≥99 | —— | ≥99.5 | ≥99.5 |
Fe?O? | ≤0.2 | ≤0.1 | —— | —— |
ZrO2 | —— | ≥15 | —— | —— |
產品規格,mm Product specification | 標準規格： 200×100×30-80（長* 寬 *高 ） Standard: 200×100×30-80 (Length * width * thickness) 也可根據用戶要求定做 In accordance with design drawing of use |
|
|
注：產品的技術數據是由所采用的測試標準得的平均值，會在一定的范圍內波動，該數據不代表產品的質量保證數據。
-
